Blu-Sub Subsea Aluminum Flange Enclosure
Blu-Sub Mechatronics
- Manufacturer
- Blu-Sub Mechatronics
- Part number
- BS-SSC-FLNGE-ALU-A1A1
- Category
- Enclosures
Subsea Aluminum Flange
An anodized aluminum flange that pairs with end-caps to form a secure, watertight seal on acrylic or aluminum enclosure tubes. Features a double O-ring design at the tube connection plus an integrated groove for end-cap installation, with side-threaded locking ports (aluminum tubes) and four set screws for mechanical retention. All required O-rings are included.
Specifications
| SKU | BS-SSC-FLNGE-ALU-A1A1 |
| Product type | Flange |
| Depth Rating | 1,000 m / 3,281 ft |
| Material | Anodized aluminum |
| Weight | 116 g (85mm), 190 g (115mm), 276 g (165mm) |
| Available Sizes | 85 mm, 115 mm, 165 mm |
| Overall Height | 32.5 mm (all sizes) |
Figures above are Blu-Sub Mechatronics published specifications as held in the Vebix Automation catalogue. Hardware revisions change them, so confirm them against the datasheet for the exact part number quoted. The manufacturer's full specification is at Blu-Sub Mechatronics's own listing (opens in a new tab).
Applications
Sealing/structural interface between enclosure tubes and end-caps in ROV enclosures, sensor housings, underwater cameras, and data pods.
Compatible accessories
Subsea Enclosure Acrylic/Aluminum Tubes; Aluminum, Acrylic, and Optical Dome End-Caps; Electronic Tray Set for Enclosure Tube
Selection guides
How to choose between the options in this category, and what to check before ordering.
Manufacturer reference
View manufacturer specifications and documentation (opens in a new tab). Check the exact variant and document revision when specifying this part.
Common questions
What is its depth rating?
1,000 m / 3,281 ft.
How much does it weigh?
116 g (85mm), 190 g (115mm), 276 g (165mm).
What is it made from?
Anodized aluminum.
What is the manufacturer part number?
Blu-Sub Mechatronics lists it as BS-SSC-FLNGE-ALU-A1A1. Quote that number on an enquiry and we will match it exactly.
Can I get the datasheet and drawings?
Yes. The Blu-Sub Mechatronics datasheet and any drawings we hold for the Blu-Sub Subsea Aluminum Flange Enclosure are sent on request -- ask for them with your enquiry and we will attach them to the reply.
How do I order this in India?
Vebix Automation is an authorised Blu-Sub Mechatronics distributor and supplies the Blu-Sub Subsea Aluminum Flange Enclosure across India from Pune. Pricing, stock, lead time and the manufacturer datasheet are confirmed on enquiry.
More in Enclosures
Enclosures selection guide & comparison →Goes with this
Other parts in this category. These are not alternatives to the part above — they are what it is installed alongside.
Get a quote for this product
Tell us the quantity and delivery location. We will confirm pricing, stock and lead time, and can help with the datasheet and compatibility.
Availability & support
Contact us for exact pricing, stock and lead time. Supplied and supported across India by Vebix Automation, an authorised Blu-Sub Mechatronics distributor, with technical support through selection, integration and after delivery. The manufacturer datasheet for this product is available on request.
Compare end caps and flanges
Manufacturer specifications for the parts this one is an alternative to, side by side. A dash means a figure is not listed in our catalogue, not zero. Check the exact variant and operating conditions before choosing.
| Product | Depth Rating | Weight | Material | Product type | Available Sizes |
|---|---|---|---|---|---|
| Subsea Aluminum Flange this page | 1,000 m / 3,281 ft | 116 g (85mm), 190 g (115mm), 276 g (165mm) | Anodized aluminum | Flange | 85 mm, 115 mm, 165 mm |
| Subsea Aluminum End-Cap | 1,000 m / 3,281 ft | 79-340 g depending on size | Black anodized aluminum | End cap | 85 mm OD (6mm thick), 115 mm OD (8mm thick), 165 mm OD (6mm thick) |
| Subsea Acrylic End-Cap | 300 m (85mm) / 200 m (115mm) / 50 m (165mm) | 46-195 g depending on size | Transparent polished acrylic | End cap | — |
| Subsea Optical Dome End-Cap | 1,000 m / 3,280 ft | 92 g dome / 160 g with ring | Clear PC dome; black anodized aluminum retaining ring | End cap | — |
| Subsea Optical Glass Flange & End-Cap (115 mm) | 300 m / 984 ft | 559 g | Black anodized aluminum + tempered borosilicate glass | Flange and end cap | — |
| Subsea Polymer Flange & End-Cap | 30 m / 98 ft (sealed, tested) | 161 g (188 g shipped) | Glass-fiber-filled nylon | Flange and end cap | — |
