Blu-Sub Enclosure Tray Shelf Support (Single-Point)
Blu-Sub Mechatronics
- Manufacturer
- Blu-Sub Mechatronics
- Part number
- Confirmed on enquiry
- Category
- Enclosures
Enclosure Tray Shelf Support (Single-Point)
One pair of single-point shelf supports for use with Blu-Sub Electronic Tray Sets (85, 115, or 165 mm sizes). Each support uses a single screw connection per end, giving a space-efficient, modular option for mounting components around larger internal parts, as opposed to the more rigid double-point variant.
Specifications
| Product type | Internal tray |
| Material | Cold-rolled steel plate, spray coated |
| Weight | 41-101 g depending on length |
| Available Lengths | 200, 250, 300, 350, 400 mm |
| Compatible Tube Diameters | 85 mm, 115 mm, 165 mm |
| Color by Length | Red (200mm), Yellow (250mm), Blue (300mm), Green (350mm), White (400mm) |
| Package Contents | 1 pair of supports + mounting screws |
Figures above are Blu-Sub Mechatronics published specifications as held in the Vebix Automation catalogue. Hardware revisions change them, so confirm them against the datasheet for the exact part number quoted. The manufacturer's full specification is at Blu-Sub Mechatronics's own listing (opens in a new tab).
Applications
Space-efficient single-point internal shelf support for electronics trays inside subsea enclosure tubes.
Compatible accessories
Electronic Tray Set for Enclosure Tube; Insulated PCB Board Shelf; Subsea Enclosure Acrylic and Aluminum Tubes
Selection guides
How to choose between the options in this category, and what to check before ordering.
Manufacturer reference
View manufacturer specifications and documentation (opens in a new tab). Check the exact variant and document revision when specifying this part.
Common questions
How much does it weigh?
41-101 g depending on length.
What is it made from?
Cold-rolled steel plate, spray coated.
Which sizes are available?
200, 250, 300, 350, 400 mm.
Can I get the datasheet and drawings?
Yes. The Blu-Sub Mechatronics datasheet and any drawings we hold for the Blu-Sub Enclosure Tray Shelf Support (Single-Point) are sent on request -- ask for them with your enquiry and we will attach them to the reply.
How do I order this in India?
Vebix Automation is an authorised Blu-Sub Mechatronics distributor and supplies the Blu-Sub Enclosure Tray Shelf Support (Single-Point) across India from Pune. Pricing, stock, lead time and the manufacturer datasheet are confirmed on enquiry.
More in Enclosures
Enclosures selection guide & comparison →Goes with this
Other parts in this category. These are not alternatives to the part above — they are what it is installed alongside.
Get a quote for this product
Tell us the quantity and delivery location. We will confirm pricing, stock and lead time, and can help with the datasheet and compatibility.
Availability & support
Contact us for exact pricing, stock and lead time. Supplied and supported across India by Vebix Automation, an authorised Blu-Sub Mechatronics distributor, with technical support through selection, integration and after delivery. The manufacturer datasheet for this product is available on request.
Compare enclosure fit-out parts
Manufacturer specifications for the parts this one is an alternative to, side by side. A dash means a figure is not listed in our catalogue, not zero. Check the exact variant and operating conditions before choosing.
| Product | Weight | Material | Compatible Tube Diameters | Available Lengths | Product type |
|---|---|---|---|---|---|
| Enclosure Tray Shelf Support (Single-Point) this page | 41-101 g depending on length | Cold-rolled steel plate, spray coated | 85 mm, 115 mm, 165 mm | 200, 250, 300, 350, 400 mm | Internal tray |
| Insulated PCB Board Shelf for Enclosure Tube | 16-179 g depending on diameter/length | Green double-sided insulated PCB material | 85 mm, 115 mm, 165 mm (internal) | 200, 250, 300, 350, 400 mm | Internal tray |
| Electronic Tray Set for Enclosure Tube | 82-294 g depending on diameter/length | Plastic-sprayed cold-rolled steel | — | 200, 250, 300, 350, 400 mm | Internal tray |
| Aluminum Tube Enclosure Mounting Plate | 82 g (wide) / 19 g (narrow) | Black anodized aluminum | — | — | Enclosure mounting hardware |
| Subsea Acrylic Tube Clamp Set | 170 g (85mm), 198 g (115mm), 295 g (165mm) | Black anodized aluminum | — | — | Enclosure mounting hardware |
