Subsea Embedded Push Button Switch (Non-Magnetic) (BS-SSC-EPBSW-SSX-10A1)
A compact, fully sealed 316 stainless steel push-button switch for underwater control interfaces. It operates as a momentary (tap) switch, conducting only while actuated and self-resetting with no latching. Its non-magnetic construction makes it safe to use near sonar and navigation instruments.
Key specifications
- Electrical Rating
- Max 50 mA @ 12 VDC; min 10 uA @ 1 VDC
- Thread Size
- M12 x 0.75
- Depth Rating
- 100 m (328 ft)
- Material
- 316 stainless steel (non-magnetic)
Before you order: Check its thread, electrical rating and depth rating.
- Part number
- BS-SSC-EPBSW-SSX-10A1
- Type
- Subsea switches, displays and indicators
- Manufacturer's range
- Blu-Sub subsea switches, potentiometers and switching boards
Includes GST and delivery in India
Imported to order. Lead time confirmed with your quotation.
Request a quotation from your cart. No payment is required to submit.
Specifications
| Product type | Push switch |
| Depth Rating | 100 m (328 ft) |
| Thread Size | M12 x 0.75 |
| Material | 316 stainless steel (non-magnetic) |
| Weight | 19.8 g |
| O-ring Size | 12 x 1 mm |
| Button Diameter / | 9 mm diameter; ~1.5 mm travel |
| Electrical Rating | Max 50 mA @ 12 VDC; min 10 uA @ 1 VDC |
| Wire | 24 AWG, ~200 mm |
| Temperature (Water) | -4 to 40 C |
| Design Lifetime | 3 years or 3,000 cycles |
Price and supplied configuration
- SKU
BS-SSC-EPBSW-SSX-10A1- Price
- ₹18,752.32
Prices are in rupees. Includes GST and delivery in India. Delivery and returns
Accessories and compatibility
Used for
- Manual input control for underwater lights, pumps, solenoids, and sealed enclosure interfaces, especially where magnetic interference must be avoided (e.g. near sonar/compass)
The manufacturer lists: Toggle Relay Control Module (adds latching behavior and long-press shutdown), O-Ring Lubricant (MOLYKOTE 111 Compound).
Questions buyers ask
What is its depth rating?
100 m (328 ft).
What is it made of?
316 stainless steel (non-magnetic).
Where is the datasheet?
The manufacturer's own page for this part is linked under Documentation on this page; its datasheet and downloads, where the manufacturer publishes them, are there. We also send the datasheet and any drawings with your quotation.
Can I return it?
Yes, within 30 days of delivery, if it is unused and in its original packaging. You pay the return shipping, and we refund 90% of the price after checking the part.
Compare with other subsea switches, displays and indicators
The manufacturers’ figures for this part and the ones most like it, on the rows they publish. — Not specified
| Product | Depth Rating | Material | Electrical Rating | Wire | Design Lifetime |
|---|---|---|---|---|---|
| Subsea Embedded Push Button Switch (Non-Magnetic) (BS-SSC-EPBSW-SSX-10A1) this page | 100 m (328 ft) | 316 stainless steel (non-magnetic) | Max 50 mA @ 12 VDC; min 10 uA @ 1 VDC | 24 AWG, ~200 mm | 3 years or 3,000 cycles |
| Subsea M10 Rotary On/Off Switch (BS-SSC-SSRSW-BLK-10A1) | 1,000 m (3,280 ft) | 6061 black anodized aluminum or 316 stainless steel | 0.5 A @ 24 VDC; 0.2 A @ 48 VDC | 24 AWG, green/blue, ~200 mm | Not specified |
| Subsea M8 Rotary On/Off Switch (BS-SSC-SSSWI-BLK-08A1) | 1,000 m (3,280 ft) | Black anodized aluminum bulkhead, red knob | 0.5 A @ 125 VAC or 0.3 A @ 28 VDC | 24 AWG, blue/green, ~200 mm | 3 years or 500 cycles at rated depth |
| Subsea M10 Tap Switch (Non-Latching) | 1,000 m (3,280 ft) | Black anodized aluminum | 0.5 A @ 125 VAC (varies by DC voltage) | 24 AWG, ~200 mm, blue/green | 3 years or 500 cycles |
| Subsea M10 Pressure Trigger Switch | 1,000 m (3,280 ft) | Anodized aluminum housing | 0.5 A @ 125 V max | 24 AWG, ~200 mm, blue/green | 3 years or 500 cycles |
| Subsea M10 Rotary Waveband Switch | 1,000 m (3,280 ft) | 6061 aluminum, black anodized bulkhead, red knob | 0.5 A @ 24 VDC; 0.2 A @ 48 VDC | 24 AWG, ~200 mm | 3 years or 500 cycles to rated depth |
