S500 V2 Development Kit (Pixhawk 6C/M10 /433MHz)
Holybro's S500 V2 Development Kit with a Pixhawk 6C, M10 GPS and 433 MHz SiK telemetry radio, on the 480 mm S500 V2 airframe. It is the S500 V2 ARF kit, with 2216 KV920 motors, BLHeli S 20 A ESCs, 1045 propellers and a 60 A integrated power distribution board, plus the avionics: a Pixhawk 6C flight controller in the plastic case, a PM02 V3 power module, an M10 GPS and a SiK Telemetry Radio V3 on 433 MHz. It suits a PX4 or ArduPilot research drone when budget matters more than payload room. No battery is included. Holybro recommends a 4S LiPo of 3000–5000 mAh, 20C or better, on an XT60; you also need an RC transmitter and receiver and a charger. Holybro SKU 30184. The other version is 30185 (915 MHz).
Key specifications
- Kit format
- Development kit — airframe, propulsion and the avionics named above
- Flight controller
- Pixhawk 6C
- Telemetry band
- 433 MHz
- Airframe
- S500 V2
Before you order: Check the flight controller and telemetry band in the kit, and what is still needed: battery, charger, RC transmitter and receiver.
Version: Pixhawk 6C, 433 MHzPixhawk 6C, 915 MHz
- Part number
- 30184
- Type
- Development kits
- Manufacturer's range
- Holybro Development Drone Kits
Includes GST and delivery in India
Imported to order. Lead time confirmed with your quotation.
Request a quotation from your cart. No payment is required to submit.
Specifications
| Manufacturer | Holybro |
| Holybro SKU | 30184 |
| Product type | Development drone kit |
| Product line | S500 V2 |
| Category | Development Drone Kits |
| Airframe | S500 V2 |
| Flight controller | Pixhawk 6C |
| Telemetry band | 433 MHz |
| Kit format | Development kit — airframe, propulsion and the avionics named above |
| GNSS receiver | Holybro M10 GPS (M10 option named in this specific development-kit SKU). |
| Wheelbase | 480 mmFrom the ARF kit this kit is built on. |
| Motors | 2216 KV920From the ARF kit this kit is built on. |
| ESCs | BLHeli S 20 AFrom the ARF kit this kit is built on. |
| Propellers | 1045From the ARF kit this kit is built on. |
| Power module | PM02 V3 |
| Telemetry radio | SiK Telemetry Radio V3, 433 MHz |
| Battery | Not included. Holybro recommends a 4S LiPo, 3000–5000 mAh, 20C or better, with an XT60 connector |
Price and supplied configuration
- SKU
30184- Price
- ₹78,703.98
Prices are in rupees. Includes GST and delivery in India. Delivery and returns
Documentation
Checked against the manufacturer's published figures: holybro.com/…/s500-v2-development-kit (opens in a new tab) (read 26 September 2026); holybro.com/…/s500-v2-kit (opens in a new tab) (read 26 September 2026).
What else you need
Parts the kit leaves out
A flight battery, a charger, and an RC transmitter and receiver.
Source: Holybro's kit contents, as set out in our S500, X500 and X650 comparison.
Questions buyers ask
Where is the datasheet?
The manufacturer's own page for this part is linked under Documentation on this page; its datasheet and downloads, where the manufacturer publishes them, are there. We also send the datasheet and any drawings with your quotation.
Can I return it?
Yes, within 30 days of delivery, if it is unused and in its original packaging. You pay the return shipping, and we refund 90% of the price after checking the part.
Compare with other development kits
The manufacturers’ figures for this part and the ones most like it, on the rows they publish. — Not specified
| Product | Airframe | Flight controller | Telemetry band | Kit format | GNSS receiver |
|---|---|---|---|---|---|
| S500 V2 Development Kit (Pixhawk 6C/M10 /433MHz) this page | S500 V2 | Pixhawk 6C | 433 MHz | Development kit — airframe, propulsion and the avionics named above | Holybro M10 GPS (M10 option named in this specific development-kit SKU). |
| S500 V2 Development Kit (Pixhawk 6C/M10 /915MHz) | S500 V2 | Pixhawk 6C | 915 MHz | Development kit — airframe, propulsion and the avionics named above | Holybro M10 GPS (M10 option named in this specific development-kit SKU). |
| X500 V2 Development Kit (Pixhawk 6C/M10/433MHz) | X500 V2 | Pixhawk 6C | 433 MHz | Development kit — airframe, propulsion and the avionics named above | M10 |
| X500 V2 Development Kit (Pixhawk 6C/M10/915MHz) | X500 V2 | Pixhawk 6C | 915 MHz | Development kit — airframe, propulsion and the avionics named above | M10 |
| X500 V2 Development Kit (Pixhawk 6X/M10/433MHz) | X500 V2 | Pixhawk 6X | 433 MHz | Development kit — airframe, propulsion and the avionics named above | M10 |
| X650 Development Kit (Pixhawk 6C/M10/433MHz) | X650 | Pixhawk 6C | 433 MHz | Development kit — airframe, propulsion and the avionics named above | M10 |
